Tipo de bici

• GRAVEL

Material del cuadro

• AL 6069 T4, T6

Peso del cuadro

• 2.8 kg (frame & fork)

Altura de horquilla recomendada / max

• 410 mm, 55 mm (offset)

Dirección

• IS 52

Ancho max cubiertas (etrto)

• 47 mm / diam 721 mm

Tamaño de rueda

• 700c on S, M, L and XL - 650b on XS

Estándar de disco

• Front F160/180 - Rear F160/180

Disco trasero

• 180 mm

Tija de sillín / Abrazadera sillín

• 27,2 mm - 30,6 mm

Caja de pedalier

• Press fit 86.5 mm

Línea de cadena

• SRAM 47,5 mm / SHIMANO 49,7 mm

Eje de rueda trasera

• 12 x 142 mm / L=175 mm, M12*P1,0 mm

Cuadro

365

• 650b, Alloy 6069, triple butted tubes, T4, T6 on XS

• 700c, Alloy 6069, triple butted tubes, T4, T6 on S, M, L, XL

Horquilla

365

• Internal brake hose routing, Alloy 6069

Dirección

ACROS IS52 / IS52

• Integrated cable routing

Potencia

RIDE ALPHA Gravel 70

• 70 mm extension, 31.8 mm

Volante

SPANK Flare 25 Drop Bar

• 31.8 mm, 440 mm width, 65 mm reach, 110 mm drop, 25° flare on XS, S

• 31.8 mm, 460 mm width, 65 mm reach, 110 mm drop, 25° flare on M

• 31.8 mm, 480 mm width, 65 mm reach, 110 mm drop, 25° flare on L, XL

Puños

SPANK Wing Gravel Dropbar Tape & Plug

• 220 cm, Black

Frenos

SHIMANO GRX RX400, Flat Mount, resin pads

• Rotors: SHIMANO SM-RT66 180 mm, 6-bolt

Pulsador

SHIMANO GRX RX600

• 11s

Desviador trasero

SHIMANO GRX RX812

• 11s

Caja de pedalier

SHIMANO BB-RS500

• Pressfit

Bielas / Plato

SHIMANO GRX RX600, 170 mm crank arms on XS/S, 172.5 mm on M/L, 175 mm on XL

• Chainring: SHIMANO GRX RX600, 40t

Cadena

SHIMANO 105

• 11s

Cassette

SHIMANO Deore M5100

• 11s, 11-42t

Aros

DT SWISS G540

• 650b, 24h, 24 mm inner width, tubeless ready on XS

• 700C, 24h, 24 mm inner width, tubeless ready on S / M / L / XL

Buje

Rear: FORMULA RX-300 - Front: FORMULA RX-812

• Rear: 24h, sealed bearings, 12 x 142 mm, Shimano Hyperglide - Front: 24h, sealed bearings, 12 x 100 mm

Radios

SAPIM Race

• J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black

Llantas

Rear: MAXXIS Rambler - Front: MAXXIS Rambler

• Rear & Front: 650x47b, EXO, Tubeless Ready on XS - 700x45c, EXO, Tubeless Ready on S / M / L / XL

Poste de asiento

RIDE ALPHA

• 27.2 mm, 350 mm length

Asiento

FIZIK Terra Alpaca X5

• 145 mm width, S-alloy rails

Peso 10,9

10.9 kg / 24.03 lb

• Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

Pedales incluidos

No

Color

Chalk

Accesorios

Down tube protector, chainstay protector, fork mudguard
